Description
Features and Specifications:
Total Dissolved Solids: 1500 ppm [Max]
TREATED WATER PARAMETERS [EX-RO PLANT]
TDS mg/l : < 75 ppm
pH: 5.5 – 6.5
LIMITING CONDITIONS
OF THE PLANT:
OXIDISING ELEMENTS: NIL
IRON: NIL
OIL & GREASE: NIL
WATER SOURCE: BOREWELL
pH: 4 – 11
CHLORINE: NIL
SDI : 3 (Max)
DESIGN PARAMETERS
FEED FLOW: 200 LPH
PERMEATE FLOW: 100 LPH
MAXIMUM INLET TDS: 1500 ppm
PERMEATE TDS : < 75 ppm
RECOVERY: 90%
INLET PRESSURE : 3.0 Kgs/cm2
booster Pump – 100 gpd (8 Pcs
POWER: 1-Phase, 220 V AC
SCOPE OF SUPPLY
CARTRIDGE FILTER [5 Micron] : 6 No.
RO MEMBRANES: 4040
- OF MEMBRANES: 1(VONTRON/TFC)
MEMBRANE HOUSING: 1
- OF HOUSING: 1(FRP)
HIGH-PRESSURE PUMP: ( Usha/Grand Forest )
SKID [MS] : One
ROF INDICATOR: Two
CONDUCTIVITY INDICATOR [0-200 μs] : One
INTERCONNECTING PIPEWORK: One Lot [UPVC
LP SWITCH [PVC]: One
Stainless Steel Frame .25 inches)
